- triple output power supply 60w
Model Number: T-120D
Output Power: 101 - 200W
Brand Name: makerele
Output Frequency: 47~63Hz
Output Type: Triple
DC Voltage: 5V 12V 24V
Rated Power: 120W
AC Current: 2.5A/115V 1.25A/230V
Voltage Tolerance: 2% 6% 6%
Voltage Adj. Range: CH1: -5%, +10%
Inrush Current: Cold start 30A/115V 60A/230V
Safety Standard: Design refer to UL 1012
Setup, Rise, Hold Up Time: 200ms,50ms,16ms at full load
Package Size: 21cm x 12cm x 7cm (8.27in x 4.72in x 2.76in)
Output Current: 8A 2.5A 2A
Please make sure the input voltage, output voltage and current in item specs when placing orders. Or we\'ll arrange the one as the item specs says.
Model T-120A T-120B
Output number CH1 CH2 CH3 CH1 CH2 CH3
DC Voltage 5V 15V -15V 5V 12V 24V
Rated Current 10A 2.5A 1A 6A 2A 2A
Current Range 2-12A 0.2-2.5A 0.1-1A 2-10A 0.1-2A 0.2-2A
Rated Power 100W 100W 100W 102W 102W 102W
Ripple & Noise 80mVp-p 150mVp-p 150mVp-p 80mVp-p 150mVp-p 150mVp-p
Voltage Adj. Range CH1: -5%, +10% CH1: -5%, +10%
Voltage Tolerance 2% 6% 6% 2% 6% 6%
Setup, Rise, Hold Up Time 200ms,50ms,16ms at full load
Voltage Range 85~132VAC 47-63Hz; 240~370VDC
AC Current 2.5A/115V 1.25A/230V
Efficiency 77% 79%
Inrush Current Cold start 30A/115V 60A/230V
Leakage Current <0.5mA/240VAC
Over Load 105%~150%
Protection type: Shut down o/p voltage, recovers automatically after fault condition is removed
Working Temp., Humidity -10C~+60C; 20%~90%RH
Storage Temp., Humidity -20C~+85C; 10%~95%RH
Vibration 10~500Hz, 2G 10min./1cycle, period for 60min, each along X, Y, Z axes
Withstand Voltage I/P-O/P:1.5KVAC I/P-FG: 1.5KVAC O/P-FG: 0.5KVAC
Isolation Resistance I/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC
Safety Standard Design refer to UL1012,
EMC Standard Design refer to FCC part 15j conditions grade B
1.All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25C of ambient temperature.
2.Ripple & noise are measured at 20MHz of bandwidth by using a 12twisted pair-wire terminated with a 0.1 &47
3.Tolerance: includes set up tolerance, line regulation and load regulation
MingWei switching power supply factory is a set design, development, production in one of the high-tech professional manufacturers, the region is the first company to introduce Taiwan manufacturer of switch power supply technology, building in May 2001.
- Custom Product Design
- Profession in export service from Maker Electric
- High quality Product, Affordable Price
Notes on choosing a switching power supply?
To increase the reliability of the S.P.S., we suggest users choose a unit that has a rating of 30% more power than actual need. For example, if the system needs a 100W source, we suggest that users choose a S.P.S. with 130W of output power or more. By doing this, you can effectively boost the reliability of the S.P.S. in your system.Make sure that the model qualifies for the safety standards and EMC regulations you need.
- What are switching power supplies?
- Switching power supplies input a commercial AC power supply (such as 110 VAC or 220 VAC), uses a high-speed semiconductor switching process to convert the input to high-frequency electric power, and yields a direct current (such as 24 VDC).
What about production process of switching power supply?
Maker Industrial and Trading Company started to run businiess since 2006, which is located in Wenzhou Yueqing - The world-famous city for low-voltage electric apparatus.We owns followed subsidiary corporations:
